Selective Removal of Cesium Values by Ion Exchange (1967)

U.S. Patent No. 3,296,123, granted on January 3, 1967, to Joseph P. Boni and William T. Bartlett, describes a specialized chemical process for selectively extracting radioactive cesium isotopes from complex, highly caustic nuclear waste solutions. Assigned to the United States of America as represented by the United States Atomic Energy Commission, the patent introduced an ion-exchange medium capable of isolating hazardous fission products without requiring pre-neutralization of extreme alkaline wastes.

This invention resolved a major operational hurdle in post-reactor nuclear waste management: how to separate trace amounts of hazardous cesium-137 from massive volumes of high-salt, highly alkaline waste solutions without generating unstable colloidal precipitates that clog filtration equipment.

The Innovation: Granular Potassium Cobalt Ferrocyanide (PCF)

When nuclear fuel undergoes neutron bombardment, fission produces high yields of cesium-137 (roughly 6.1%). With a 30-year half-life and potent beta and gamma emissions, cesium-137 represents roughly 98% of the supernatant radioactivity in alkaline nuclear storage tanks after several years of cooling.

Prior methods relied on direct or carrier precipitation, adding soluble potassium ferrocyanide and heavy-metal salts directly to the waste. This conventional approach suffered from severe drawbacks:

• Peptization into Colloids: Carrier precipitates rapidly broke down into fine colloidal suspensions that resisted gravity settling, centrifugation, and remote-controlled industrial filtration.
• Narrow pH Limits: Traditional ferrocyanide precipitation failed in the highly alkaline environments (pH greater than 13) typical of nuclear reprocessing waste, demanding dangerous and expensive acid-neutralization steps beforehand.

Boni and Bartlett discovered that synthesizing potassium cobalt ferrocyanide (PCF) under strict stoichiometric and thermal conditions produces discrete, robust crystalline granules. Rather than acting as a sloppy carrier precipitate, this preformed granular PCF functions as a true solid-bed ion-exchange medium that exhibits exceptional selectivity for cesium across an unprecedented pH range (pH 1 to 14).

Why Granular PCF?

• Alkaline and Radiation Stability: Unlike conventional resins or unstructured precipitates, granular PCF resists chemical dissolution in boiling concentrated acids as well as hot, concentrated alkaline salts (1M sodium hydroxide and 4M sodium nitrate), while withstanding severe ionizing radiation fields without degrading.
• Resistance to Peptization: The precise crystalline formulation maintains structural integrity, eliminating the colloidal slimes that historically blinded filters in remote-handling radioactive facilities.
• Extreme Sorption Selectivity: PCF selectively captures trace cesium ions even in the presence of overwhelming concentrations of competing alkali and alkaline earth cations (such as sodium, potassium, calcium, and aluminum).
• Universal pH Tolerance: Operates directly on raw acidic reprocessing streams or high-level alkaline aged tank supernatants (pH 14) without requiring prior chemical neutralization.

Key Chemical Components

The system coordinates specific inorganic reagents to synthesize the stable ion exchanger and run the separation cycle:

Component: Function

Potassium Ferrocyanide Solution (K4Fe(CN)6): Supplies the hexacyanoferrate complex backbone, buffered at pH 5.3 with sodium acetate during synthesis.

Cobalt Nitrate Solution (Co(NO3)2): Added in a 40% to 50% stoichiometric excess to prevent colloid formation and drive complete crystallization of the insoluble green PCF complex.

Granular PCF Bed (K2[CoFe(CN)6] / Co[CoFe(CN)6]): The preformed solid-state ion-exchange matrix, graded to discrete mesh fractions (optimally 30 to 60 mesh) to balance surface sorption speed with hydraulic bed throughput.

Eluting Agents (Thallium Nitrate or Mercuric Nitrate): High-affinity stripping solutions (e.g., 0.02M TlNO3) that elute captured cesium values from the packed bed for isotope recovery.

Performance: Decontamination of High-Level Wastes

The patent presents rigorous empirical data gathered on real and simulated radioactive waste streams:

• Extreme Volumetric Efficiency: In low-level salt solutions, a fixed bed of 30 to 60 mesh PCF achieved 99.9% cesium removal across more than 40,000 bed volumes.
• High-Level Waste Decontamination: On real six-year-old aged radioactive waste holding one curie of cesium-137 per liter at pH 14, PCF treatment stripped 96% to 99% of all cesium activity.
• Rapid Kinetics: Contact batch testing demonstrated that the material reaches sorption equilibrium rapidly, taking up over 95% of available cesium within one hour.
• High Elution Recovery: Passing seven bed volumes of 0.02M thallium nitrate eluted greater than 99% of the sorbed cesium from the loaded exchange material.

The Manufacturing Process

The inventors developed an exact recipe to ensure the ferrocyanide formed rigid, non-peptizing crystals rather than colloidal fines:

1. Prepare a 0.5M potassium ferrocyanide solution buffered at pH 5.3, and a separate 0.3M cobalt nitrate solution.
2. Slowly add the ferrocyanide solution to a 40% to 50% stoichiometric excess of the cobalt nitrate solution over 20 minutes under vigorous air sparging, maintaining temperature strictly at or below 15°C (and never above 30°C).
3. Agitate the resulting green slurry for 10 minutes, centrifuge, and wash the resulting cake with cold water at 5°C.
4. Dry the cake in one-inch layers at 115°C to 120°C (strictly below 150°C) until reaching constant weight.
5. Crush the dried cake and screen through sieves to obtain a 30 to 60 mesh cut, washing away fine dust smaller than 100 mesh, followed by final redrying at 110°C.

Historical and Scientific Impact

Conducted under the auspices of the U.S. Atomic Energy Commission during the Cold War, Boni and Bartlett’s development had immediate implications for industrial radiochemistry and environmental management:

• Volume Reduction in Nuclear Waste: By selectively isolating the long-lived, heat-generating cesium-137 isotope, bulk radioactive supernatants could be reclassified or solidified into lower-hazard waste forms, drastically cutting high-level storage costs.
• Radioisotope Harvest for Peaceful Uses: Enabled the practical recovery and concentration of high-purity cesium-137 sources for commercial teletherapy, industrial radiography, food irradiation, and isotopic power generators (atomic batteries).
• Foundation for Inorganic Sorbents: Established the synthesis parameters for transition metal hexacyanoferrate compounds, inspiring subsequent generations of Prussian blue-derived selective sorbents used globally in nuclear effluent treatment.

About the Inventors: Joseph P. Boni and William T. Bartlett

Joseph P. Boni and William T. Bartlett were research chemists associated with major U.S. Atomic Energy Commission contractor laboratories. Working in radio-analytical chemistry and nuclear fuel reprocessing, their research focused on solving separation engineering bottlenecks encountered when treating high-level fission product wastes. Their identification of the critical relationship between low-temperature precipitation, stoichiometric cobalt excess, and mechanical granule stability turned an intractable laboratory precipitate into a reliable industrial separation process.

Summary of Claims

The patent explicitly claims:

• A process for selectively removing cesium values from aqueous solutions across a pH range of 1 to 14 by contacting the liquid with preformed stable particles of potassium cobalt ferrocyanide (PCF).
• A precise preparation method requiring the addition of potassium ferrocyanide to an aqueous solution containing a 40% to 50% stoichiometric excess of a cobalt salt at temperatures below 30°C, followed by drying below 150°C to generate crystalline granules larger than 200 mesh.
• A recovery method comprising the sorption of cesium values on preformed PCF granules followed by selective elution using an aqueous solution of thallium nitrate or mercuric nitrate.
